Structural · S-HT7NQ

Deck Spanning Perpendicular to Beam

Materials

Elements

About this detail

A concrete slab is poured over a metal deck supported by a structural steel beam, with conditions for both deck spanning parallel and perpendicular to the beam. The assembly includes continuous number four reinforcing bars and welded wire reinforcement lowered as needed to place the top bar. Edge forms and closures are provided per the deck supplier specifications, with studs coordinated and edge forms notched for a maximum one-half inch clearance to the stud. Shoring is applied as needed until the concrete reaches its design strength.
