A cold-formed steel track header connects to a vertical jamb stud sized per schedule. The track flange is cut and bent, fastened with two number 10 screws near side and far side. As an alternate to the cut-and-bent flange detail, an L54 mil 1-1/2 inch by 1-1/2 inch by 5-1/2 inch long angle connects the assembly with three number 10 screws on each leg. A minimum 4-inch vertical clearance dimension is maintained at the header junction.
A TRACK SEE SCHED JAMB STUD SEE SCHED CUT TRACK FL & BEND W/ (2) #10 SCREWS NS & FS (1) #10 SCREWS NS & FS L54 MILx1 1/2"x1 1/2"x5 1/2" LONG W/ (3) #10 SCREWS EA LEG AS ALTERNATE TO CUT & BENT FLANGE DETAIL MIN 4" SECTION A
