A davit socket is mounted to a structural steel beam flange at a concrete filled metal deck roof with a variable offset at the column. Reinforcement includes four number 5 bars at 6 feet zero inches each way, with standard hooks provided at the slab edge where applicable. The assembly accommodates the top of roofing elevation and includes designated locations for davit sockets designed by others.
TYPICAL AT ALL DAVIT SOCKETS AT CONC FILLED DECKS (ADD (4)# 5x6'-0" EW. PROVIDE STANDARD HOOK AT SLAB EDGE WHERE OCCURS) PL OR BEAM FLANGE TOP OF ROOFING DAVIT SOCKET DESIGN BY OTHERS (OFFSET AT COLUMN) DAVIT SUPPORT AT BEAM D VARIES 1'-8" 3/8 TYP
