An L3x3x1/4 angle provides slab support at column penetrations where no beam or other support is present. The angle attaches to a wide flange column or an alternate angle location as sized per plan. Slab support angles are required at all column locations where there is no beam or other support for the slab at the column penetration.
ALTERNATE ANGLE LOCATION L3X3X1/4 SLAB SUPPORT WIDE FLANGE COLUMN, SEE PLAN WIDE FLANGE BEAM, SEE PLAN DECK SPAN DIRECTION NOTES: 1. SLAB SUPPORT ANGLES ARE REQUIRED AT ALL COLUMN LOCATIONS WHERE THERE IS NO BEAM OR OTHER SUPPORT FOR SLAB AT COLUMN PENETRATION. CENTERLINE OF COLUMN 3/4" = 1'-0" SE5-11 C5 SLAB SUPPORT AT TUBE COLUMN
