Grade beam reinforcing bars extend into the concrete pile cap and connect via a lap splice. Dowels match the grade beam reinforcing and either extend through the pile cap or terminate with a hook at the far end. Main grade beam reinforcing ties into the pile cap assembly as referenced on plan.
DOWELS TO MATCH GRADE BEAM REINFORCING EXTEND THRU PILE CAP OR HOOK AT FAR END PILE CAP REF. PLAN REINFORCING NOT SHOWN GRADE BEAM REF. PLAN GRADE BEAM REINFORCING LAP SPLICE
