A typical steel beam splice connection utilizes a shear plate with bolts and beam web stiffeners. The connection maintains a one-half inch gap between beam ends and incorporates five-sixteenths inch and one-quarter inch fillet welds. Stiffener plates are matched to the shear plate thickness and welded full height on both sides where indicated on the structural plans.
BS PROVIDE STIFFENER WHERE INDICATED ON PLAN THUS MATCH SHEAR PL "t" & WELD FARSIDE FULL HEIGHT BOTH SIDES TYPICAL BEAM SPLICE 2" 5/16 3 SIDES 1/4 4" 3" 1/2" SEE SCHEDULE
