A supported steel beam connects to the web of a supporting steel beam using a single plate shear tab welded to the support and bolted to the supported beam web. Dimensions indicate a typical one-half inch clearance gap at the beam ends and a two-inch minimum edge distance for the bolt group. Additional information refers to detail A and note three for specific sizing and configuration per plan.
SEE NOTE 3 BM PER PLAN 1/2" TYP SEE "DETAIL A" FOR ADDITIONAL INFORMATION Detail B: Single Plate Beam to Beam Connection 1/2" TYP 2" MIN 1 1/2" MAX 2" MIN
