A wide-flange steel section features corner clips at the intersection of the web and flanges with a minimum one-half-inch radius. Dimensional tolerances specify an allowable variation of zero to plus one-quarter inch vertically, and minus one-quarter to zero inches horizontally. These clipping and radiusing requirements prevent crack propagation and accommodate the fillet of the structural shape.
NOTES: 1. ALLOWABLE TOLERANCE (-0", +1/4"). 2. ALLOWABLE TOLERANCE (-1/4", +0"). 3 1/2" 2 5/8" k (NOTE 2) k + 1 1/2 (NOTE 1) det 1 R= 1/2" MIN 10 TYPICAL CONTINUITY PLATE CLIP
