A steel column base plate assembly centers on a concrete footing pocket with a surrounding control joint. The Grade 50 base plate measures 2 1/2 inches thick and is secured using thirteen 2-inch diameter F1554 Grade 36 anchor bolts equipped with 3/4-inch by 4-inch by 0'-4" washers and double nuts. The concrete pocket requires a minimum 2-inch clearance and 6-inch minimum dimension, reinforced with centered number 4 trim bars. Infill concrete is specified to be cast after the column base plate has been grouted. A minimum thread projection of 1/2 inch is required above the top of each nut.
2'-0" 4'-6" C L C L C L C L C L C L C L 3 1/2" 11 1/2" 11 1/2" 8" 8" 8" 3 1/2" TYP 4" C L 8 1/2" 8 1/2" 3 1/2" CL COL CL COL GR50 BASE PL2 1/2 x AS SHOWN W/ (13) 2"Ø F1554 GR36 AB'S W/ PL3/4x4x0'-4" WASHERS & DBL NUTS STL COL PER EL (ROTATED 90° ON BASEPLATE @ SIM) FTG POCKET AS SHOWN 1/2 1/2 1/2 1/2 TYP NOTES: 1. PROVIDE MINIMUM THREAD PROJECTION OF 1/2" ABOVE TOP OF EACH NUT. 2. REFERENCE DETAIL 17/S3.22 FOR SLAB CONTROL JOINT. CONTROL JOINT OR CONST JOINT PER 19/S3.22 INFILL CONC TO BE CAST AFTER COL BASE PL HAS BEEN GROUTED #4 TRIM BAR, CTRD, TYP STL COL PER PLAN (CTRD ON BASE PL AT SIM) BASE PL & AB'S PER PLAN CONC FTG POCKET PER PLAN TYP 2" CLR TYP 6" MIN CL COL CL COL
