Structural · S-HJJHC

Shearwall

Materials

Steel Timber / Wood

Elements

Columns Walls

Connections

HSS Connection Welded Connection

About this detail

Wood stud shearwall framing connects to a hollow structural section steel column at T, L, and end or continuous wall intersections. Wood nailers are fastened to the steel column using welded studs spaced per the schedule below, with the first welded stud located seven stud diameters from each end of the nailer. Shear plywood sheathing is applied at typical locations where specified. A schedule defines stud diameters, spacings, and nailer sizes for various shearwall types.
