An existing concrete column and embedded steel column are wrapped with two layers of Tyfo SEH-51A composite system oriented horizontally, anchored by five-eighths inch diameter Tyfo SCH composite anchors spaced at twelve inches on center. The surrounding corners are rounded to a half-inch radius typical, with existing reinforcement left undamaged. An existing opening is infilled with concrete reinforced with number four U-bars at twelve inches on center using adhesive anchors into existing concrete, and two continuous number seven bars. The assembly ties into an existing brick wall along a structural grid line.
D EMBED 4" VIF 6" VIF 1' - 0" VIF 6" VIF 1" VIF 1' - 0" VIF 5" (E) CONC COL (E) REINF. TYP. DO NOT DAMAGE (E) STEEL COL EMBEDED IN CONC. WHERE OCCURS ROUND CORNERS TO 1/2" RADIUS. TYP (2) #7 BARS CONT. INFILL (E) OPENING W/ CONC. #4 U BARS @ 12" OC ADHESIVE ANCHOR TO (E) CONC. 5/8"Ø TYFO SCH COMPOSITE ANCHORS @ 12" OC 2 LAYERS OF TYFO SEH- 51A SYSTEM ORIENTED HORIZONTALLY (E) BRICK WALL GRID
