Conduit is installed within the middle third of the concrete slab depth, maintaining a maximum of three conduits per group unless specific spacing is met. Individual conduits require a diameter less than or equal to one-third of the slab thickness and must maintain clear spacing of diameter D or two inches minimum. Additional number four reinforcing bars top and bottom at twelve inches on center are required where eight-inch minimum spacing between groups is not maintained. Conduits must not be placed within forty-eight inches of any column face or slab edge, and aluminum materials are strictly prohibited from being embedded in concrete. Plastic chairs are provided to support the conduit during placement.
TYP UNO D OR 2" MIN T PER PLAN IN MIDDLE THIRD PLACE CONDUIT OF SLAB DEPTH 1'-0" TYP 8" MIN UNO D TYP #4 T&B @ 12"OC REQD WHERE 8" MIN SPACING BTWN GROUPS IS NOT MAINTAINED (3) CONDUIT PER GROUP MAX CONDUIT (D < T/3) TYP UNO 1. ALUMINUM MATERIALS SHALL NOT BE EMBEDDED IN CONCRETE. 2. CONTRACTOR SHALL SUBMIT SHOP DRAWINGS WHICH INDICATE THE PLACEMENT OF CONDUIT IN SLAB. 3. DO NOT PLACE CONDUIT WITHIN 48" OF COLUMN FACE OR SLAB EDGE. 4. PROVIDE CHAIRS TO SUPPORT CONDUIT. 5. CONDUIT PLACEMENT NOT MEETING ABOVE CRITERIA MAY REQUIRE ADDITIONAL REINFORCING AND/OR SLAB THICKENING. NOTES: CONC SLAB PER PLAN T/SLAB PER PLAN
