A hollow structural section header is located relative to the structural grid and bottom of steel elevation as sized per plan. Steel studs provided by others attach to the header using bearing clips provided by others. Architectural finishes enclose the assembly on the exterior face. Dimensions and clearances are coordinated with architectural drawings.
GRID SEE PLAN BEARING CLIP BY OTHERS STL STUDS BY OTHERS ARCH FINSH HSS HDR SEE PLAN SEE ARCH BOS SEE PLAN
