A wide-flange beam connects to a column through a gusset plate and a bolted shear tab assembly. The gusset plate features a stiffener plate and complete joint penetration welds at the top and bottom flanges. A doubler plate is positioned at the connection where required, and the brace and gusset are detailed by the buckling-restrained brace manufacturer. A three-sixteenths inch fillet weld secures the doubler plate, and a five-sixteenths inch fillet weld is specified at the gusset connection. Bottom flange bracing ties into the assembly as referenced on structural details.
S7.3 2 MAX 1" TYP 1 1/2" 2" 4" 2" BRACE & GUSSET TO BE DETAILED BY BRB MFR BOTTOM FLANGE BRACING, SEE 15 S7.1 GUSSET BEYOND OF GUSSET PL AT GRIDLINE. SKEW BEAM IF NEEDED WF BEAM SEE ELEV NOTE: FOR SHEAR TAB PLATE, WELDS, AND BOLTS SEE 1 S7.3 GUSSET STIFF PL TO BE DETAILED BY BRB MFR CJP T&B TYP PITCH DOUBLER PL WHERE OCCURS, SEE 1 S7.3 9 S7.3 5/16 14" MIN 1/2" 1/2" DOUBLER PL OF GUSSET PL AT GRIDLINE. SKEW BEAM IF NEEDED PLAN NOTE: FOR DETAILS NOT SHOWN OR NOTED, SEE 5 S7.3 SHEAR TAB WF BEAM 3/16
