A steel column base plate plan features dimensions and anchor bolt placements. A four-bolt anchor pattern is positioned symmetrically at the corners with typical one-and-a-half-inch edge clearances. A centered four-inch diameter grout hole is provided with a size matching the anchor bolt hole size. Fillet welds of five-sixteenths inch or AWS minimum size connect the column profile to the base plate.
SEE PLAN SEE PLAN PLAN OR AWS MIN 5/16 1 1/2" TYP. EQ EQ 1 1/2" TYP. WIDTH SEE SCHED 1 1/2" TYP. EQ EQ 1 1/2" TYP. LENGTH SEE SCHED 4" GROUT HOLE ON BASE PLATE - SIZE OF HOLE SAME AS ANCHOR BOLT HOLE SIZE
