An HSS girt frames into a wide flange column with an L6x4x3/8 angle bracket welded at the top and bottom with a 1/4-inch fillet weld typical at each in-framing girt. A clearance gap of up to 5/8-inch is maintained at the column flange face, with a 1/2-inch maximum spacing along the side. The girt aligns with the column centerline, maintaining typical installation tolerances.
COLUMN CENTERLINE 1/2" TYP 1/4 TYP 1/4 1/2" MAX L6 x 4 x 3/8 (T&B) LLV TYP AT EACH IN-FRAMING GIRT HSS GIRT PLAN VIEW MAX 5/8"
