Welded shear studs are arranged in single and double row configurations on a steel beam top flange. Three-quarter-inch diameter studs are spaced at twenty-four inches maximum typically unless otherwise noted. Edge distances require one and one-half inches minimum for single rows and three inches minimum for double rows. Additional information refers to general notes for shear connectors and the steel deck schedule for stud lengths.
PLAN (DOUBLE ROW) PLAN (SINGLE ROW) NOTES: 1. SEE GENERAL NOTES, "SHEAR CONNECTORS" FOR ADDITIONAL INFORMATION. 2. SEE STEEL DECK SCHEDULE FOR STUD LENGTHS. BEAM TOP FLANGE 3/4"Ø STUDS TYP UON 4 1/2" MIN 24" MAX 4 1/2" MIN 24" MAX 3/4"Ø STUDS TYP UON 1 1/2" MIN 1 1/2" MIN 3" MIN
