A reinforced concrete footing supports a concrete pedestal with vertical dowels matching the pedestal reinforcement and three additional sets of ties placed at the top of the pilaster. The pedestal features number four ties spaced at twelve inches on center with lap splices and additional ties at each end of the splice. A precast panel connects to the wall per the precast manufacturer, while steel elements exposed to earth receive a protective coating and exposed structural steel is galvanized. Waterproofing is coordinated per architectural drawings.
GL GL DOWELS TO MATCH PEDESTAL VERTICAL REINF NOTES: 1. PROVIDE COATING ON ALL STEEL EXPOSED TO EARTH PER IN GENERAL NOTES. 2. EXPOSED STEEL TO BE GALVANIZED. 3. WATERPROOFING RE: ARCH. LAP SPLICE 1 ADDL SET OF TIES AT EACH END OF LAP SPLICE T/ FOOTING SEE PLAN T/ SLAB SEE PLAN CONC PEDESTAL, REINF RE: SCHED 3 ADDL SETS OF TIES AT TOP OF PEDESTAL 4" #4 TIES @12" OC PROVIDE (3) ADDL #4 TIES @ TOP OF PILASTER 0'-3" MAX SEE PLAN 5'-6" MAX SEE ARCH SEE ARCH 2" TYP SEE PLAN PRECAST CONNECTION PER PRECAST MANUFACTURER RE: FOOTING SCHEDULE FOR REINFORCEMENT T/ PEDESTAL RE: PLAN -2'-0" UON 2" EQ UON EQ UON 3" CLEAR LAP SPLICE SEE SCHEDULE PRECAST PANEL T/WALL RE: PLAN -2'-0" UON SEE 12/S-60003 12/ S-60003
