An HSS guide rail support is attached to a wide-flange beam per plan using a pair of L6x3 1/2x1/2 angles on each side. The connection utilizes three-quarter-inch machine bolts hand-tightened through thirteen-sixteenths-inch by one-seven-eighths-inch vertical slotted holes. A one-inch minimum gap is maintained between the assembly components. The metal deck and fill are detailed per plan above the structural framing, with quarter-inch welds on three sides.
1" GAP MIN A SECTION A-A WF BEAM PER PLAN L6x3 1/2x1/2 EA SIDE W/ 13/16"x1 7/8" VERT SLOTTED HOLE 3/4" MB HAND TIGHTEN HSS GUIDE RAIL SUPPORT OFFSET, S.A.D. 1/4 3 SIDES METAL DECK & FILL PER PLAN HSS GUIDE RAIL SUPPORT PER ELEV HSS C L A A HSS 3" 2" NOTES: 1. FOR INFO NOT SHOWN SEE DETAIL 6/-
