A hollow structural section post connects to a spreader beam per plan with a quarter-inch thick plate on each side secured by two three-quarter-inch diameter through-bolts in horizontal short slotted holes. A maximum one-half-inch gap is maintained between the members. Three-sixteenths-inch typical fillet welds join the assembly. A top of steel elevation is maintained per plan.
T/STL PER PLAN 1" MAX 1/2" GAP AT BEAM BEAM PER PLAN SECTION PL1/4, TYP THRU BOLTS, TYP HSS PER PLAN PL 1/4x4x0'-6" EA SIDE W/ (2) 3/4"Ø THRU BOLTS IN HORIZ SHORT SLOTTED HOLES BEAM PER PLAN 3/16 3/16 TYP HSS BEAM PER PLAN SECTION 3" TYP 1 1/2" 1 1/2"
