The strand tendon ground anchor assembly consists of steel tendons secured by an anchor head and wedges bearing against a steel bearing plate and trumpet. A PVC or polyethylene tube houses the unbonded length of the tendon, which includes a tension ring to resist splitting forces from deflected strands and non-structural filler. Spacers and centralizers maintain tendon alignment within the anchor grout along the minimum ten-foot bond length.
4 2 3 9 1 10 7 5 6 8 ANCHOR HEAD AND WEDGES BEARING PLATE TRUMPET PVC OR POLYETHYLENE TUBE SPACER GUTS (TENDONS) CENTRALIZER ANCHOR GROUT TENSION RING TO RESIST SPLITTING FORCES OF DEFLECTED STRANDS NON-STRUCTURAL FILLER 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. SEE PLANS NO LOAD ZONE ANCHOR LENGTH TENDON UNBONDED LENGTH MIN. TENDON BOND LENGTH = 10'
