A concrete wall supports a concrete slab at an elevation of 91 feet, 0 inches, featuring an embedded transformer exhaust plenum. The wall is reinforced with number 4 bars spaced at 12 inches on center horizontally and vertically, positioned centrally in the wall with a 1 1/2-inch clearance. Additional number 4 reinforcing bars run each way in the assembly. A keyway is provided per typical details between the wall and slab transition.
EL = 91'-0" 6" 8" 8" CLR 1 1/2" #4 @ 12" VERT, CTR IN WALL #4 @ 12" HORIZ #4 @ 12" EW #4 @ 12" EW KEY PER TYP DETS CONC WALL PER PLAN CONC SLAB PER PLAN TRANSFORMER EXHAUST PLENUM
