This structural detail specifies a twelve-inch thick concrete slab on grade reinforced with number five reinforcing bars placed at twelve inches on center each way. The heavy slab assembly is designed specifically for installation below x-ray equipment.
FS12.5 12" THICK CONCRETE SLAB ON GRADE W/ #5 @ 12" O.C. E.W. BELOW X- RAY EQUIPMENT
