A slab-on-grade concrete joint features one-inch diameter by sixteen-inch long smooth dowels spaced at twelve inches on center across the joint interface. The concrete slab includes macrosynthetic fibers and additives per the eco-slab system, with reinforcing and thickness sized per plan. The joint is finished with one-eighth-inch tooled edges and maintains standard clearances.
3 CONCRETE STAIR ON GRADE NTS 3-SD1(12) 1"Ø x 16" LONG SMOOTH DOWELS @ 12"OC 2 3/8" ± 3/4" CLR TYP t" t/2 t/2 SOG SEE PLAN REINF PER PLAN GRID EQ EQ MACROSYNTHETIC FIBER AND ADDITIVE PER ECO-SLAB SYSTEM NOTE: 1/8" TOOLED EDGES 3" 3"
