An L8x4x1/2 angle member with long leg vertical is connected with a three-eighths inch fillet weld. A three-quarter inch by twelve inch square minimum plate is provided and increased in size as required. Clearances include a two inch minimum and a maximum dimension sized per plan up to eight inches.
PLAN L8x4x1/2 (LLV) 1 1 PL 3/4"x12" SQ MIN (INCREASE SIZE AS REQ'D) (8" MAX) SEE PLAN (8" MAX) SEE PLAN 2" MIN 3/8
