This structural detail shows a precast column base plate supported by four anchor rods in a rectangular configuration. A dimension of 10 feet 4 inches establishes the offset from the column centerline to the intersecting grid line. The dashed profile indicates the rectangular footprint of the base plate surrounding the steel column section designated as SC1.
