A structural steel framing detail showing a beam connected to the flange of a wide flange column using a typical shear plate connection. The framing beam is positioned per plan with its top of steel elevation coordinated accordingly. A vertical shear plate is welded to the column flange and bolted to the beam web with a typical bolt configuration. The column centerline and member sizes are specified per the structural framing plan.
BEAM TO WIDE FLANGE COLUMN FLANGE SHEAR PLATE INFORMATION PER TYPICAL SHEAR PLATE CONNECTION. COL PER PLAN TYP SHEAR PL CONN BEAM PER PLAN, TYP CL COL BEAM TO WIDE FLANGE COLUMN WEB - OPTION 1 (BEAM FITS INSIDE COLUMN) SHEAR PLATE INFORMATION PER TYPICAL SHEAR PLATE CONNECTION. BEAM WHERE OCCURS PER PLAN T/STL PER PLAN
