The slab on grade rests on a leveling course of fine-grained aggregate, sandy gravel, or crushed rock over undisturbed soil, with a vapor barrier placed above the base course. A one-eighth-inch premolded strip is installed flush with the surface for formed joints. Saw-cut joints require a one-eighth-inch cut performed on the same day as the pour, filled subsequently with joint sealer. Joint depths are dimensioned to one-quarter of the slab thickness (T/4). Base course thickness is subject to increase as required by the geotechnical engineer for wet weather construction.
VAPOR BARRIER ABOVE LEVELING COURSE OF FINE GRAINED AGGREGATE SANDY GRAVEL OR CRUSHED ROCK. INCREASE THICKNESS OF BASE COURSE AS REQUIRED BY GEOTECHNICAL ENGINEER FOR WET WEATHER CONSTRUCTION UNDISTURBED SOIL SAW CUT JOINT FORMED JOINT 1/8" PREMOLDED STRIP FLUSH w/ SURFACE 1/8" SAW CUT (SAW SAME DAY AS POUR) FILL w/ JOINT SEALER 1/8" TYP. 1/8" TYP. "T" "X" T/4 T/4
