A structural steel column is encased in concrete with welded wire fabric designated as WWF 6x6-W1.4xW1.4 surrounding the profile. One number five reinforcing bar is provided at each corner, and these bars do not need to be doweled from the foundation. The concrete encasement maintains a six-inch dimension and a three-inch clear cover as indicated. Equal concrete coverage is required for anchor bolts and base plates.
6" TYPICAL STEEL COLUMN CONCRETE ENCASEMENT DETAIL 10 3" WWF6x6-W1.4xW1.4 PROVIDE (1)#5 AT EACH CORNER. BARS NEED NOT TO BE DOWELED FROM FOUNDATION NOTE: PROVIDE SAME COVERAGE FOR ANCHOR BOLTS AND BASE PLATES TSC501
