An intermediate wide-flange beam connects to a wide-flange column web using a double-row bolted shear plate detailed per the schedule. One-half-inch Grade 50 plates are welded top and bottom to the column flange with five-sixteenths-inch fillet welds. A one-inch clearance is maintained between the beam end and the column web, with a half-inch maximum gap. Additional shear plate and bolt configurations follow the typical special seismic force-resisting system collector beam connection detail.
BEAM-TO-COLUMN WEB CONNECTION (INTERMEDIATE) a CL 5/16 5/16 (T&B) TYP PL 1/2 (T&B) GR 50 COLUMN FLANGE-TO-FLANGE TYP TYP 1/2" MAX TYP 1 1/2" TYP 3" COL CLR 1" Wx BEAM PER PLAN Wx COL PER PLAN CL COL 2" TYP 3" TYP 3" W W 5/16 5/16 (T&B) PL TO COL FLANGE, TYP DIM a SHEAR PLATE AND BOLTS PER TYPICAL SFRS COLLECTOR BEAM CONN DETAIL DOUBLE-ROW BOLTED CONNECTION PER SCHEDULE ON SFRS COLLECTOR BEAM PER TYPICAL Wx BEAM CONN DETAIL DOUBLE-ROW BOLTED CONNECTION NOTES: 1. PROVIDE SFRS COLLECTOR BEAM BOLTED DOUBLE-ROW CONNECTION TO COLUMN WHERE SHOWN THUS ON PLAN: REFER TO SCHEDULE FOR REQUIRED NO. OF BOLTS
