Post-tensioning tendons are routed within a concrete slab with structural tendons draped according to low and high point dimensions shown on the plan. Temperature and shrinkage tendons are located within the middle third of the slab thickness. Plastic-coated supports maintain tendon elevation, and two continuous number four bars are placed at all post-tensioning anchors.
PLASTIC COATED SUPPORT P-T CONCRETE SLAB, SEE PLAN STRUCTURAL TENDONS, SEE PLAN FOR DIMENSIONS TO TENDON CENTERLINE AT LOW AND HIGH POINTS. DRAPE TENDONS PER G.S.N. TEMPERATURE AND SHRINKAGE TENDONS. LOCATE WITHIN MIDDLE THIRD OF SLAB THICKNESS PER DETAIL 3/S-511 (2) #4xCONT BARS AT ALL P-T ANCHORS 1
