Concrete slab on steel decking supported by parallel structural steel beams. The metal deck is spread as required for studs where beams run parallel to the deck. Welded studs anchor the slab to the steel framing, with a continuous number three bar wired to the studs to support welded wire fabric or reinforcement. Additional reinforcement includes number three bars at twelve inches on center at W24 and deeper beams. Clearances maintain one inch to welded wire fabric and three-quarters of an inch to rebar typical. Minimum bearing requirements are provided at the edge beam and intermediate framing members.
ADD #3x6'-0" @ 12"OC AT W24 AND DEEPER BEAMS STEEL DECKING PARALLEL TO BEAMS SPREAD DECK AS REQ'D FOR STUDS WHERE BEAMS ARE PARALLEL TO DECK STEEL DECK SEE PLAN AND SCHEDULE WELDED STUDS AS REQUIRED #3 CONT BAR WIRED TO STUDS, TYP (TO SUPPORT WWF OR REINF) EDGE BEAM SEE PLAN WWF WHERE OCCURS BEAM - SEE PLAN 1" CLR (TO WWF) TYP SEE DETAIL "A" SEE TYP SLAB EDGE DETAIL AT EXTERIOR AND PERIMETER BEAMS L1 L2 L3 3" MIN BEARING 2" MIN SEE PLAN AND SCHEDULE . 3/4" CLR (TO REBAR) TYP . B .
