Sloped beam connections detail welded end plates and structural steel angles configured for varying beam inclination angles from zero to sixty degrees. The end plate detail specifies fillet weld sizes ranging from five-sixteenths to one-half inch and three-eighths inch, alongside web beveling requirements keyed to specific angle thresholds. Additional details illustrate both bolted beam-to-bolted support and welded beam-to-bolted support angle configurations fastened with structural bolts and typically welded on three sides with five-sixteenths inch fillets.
A 7º < Θ ≤14º 14º < Θ ≤22º 22º < Θ ≤45º, BEVEL END OF BM WEB AT END PLATE 45º < Θ ≤60º 0º < Θ ≤7º Ø (3/8) 5/16 3/8 5/16 3/8 5/16 7/16 5/16 1/2 5/16 0º = Θ 5/16 5/16 ANGLES - BOLTED BEAM / BOLTED SUPPORT ANGLES - WELDED BEAM / BOLTED SUPPORT 5/16 3 SIDES, TYP END PLATE
