A concrete slab section is reinforced with vertical studrails and top and bottom reinforcement bars. The studrail assembly consists of vertical studs positioned with a one-inch concrete cover at the top and three-quarter-inch concrete cover at the bottom. Studs are specified as one-half inch in diameter and must be placed vertically within the concrete slab. Studrails are provided per Decon ICC ESR-2494 and LARR 25395, with lengths determined unless otherwise noted.
TOP REINF BOTTOM REINF ALL STUDS TO BE PLACED VERTICALLY AND TO BE 1/2" DIA PROVIDE STUDRAILS BY DECON (ICC ESR-2494) LARR 25395. STUDRAIL LENGTHS SHALL BE AS FOLLOWS UNO: TYPICAL SECTION FOR STUDRAIL CONC COVER 3/4" CONC COVER 1" NOTES: 1. 2. 3.
