Reinforced concrete wall corners and intersections are detailed with horizontal lap splices and vertical reinforcement mats. Double-mat configurations incorporate four number five vertical bars typically unless noted otherwise, with ninety-degree hooks or optional corner bars at corners. Single-mat configurations utilize two number five vertical bars typically with alternate bends. Horizontal reinforcing bars maintain lap splices across intersecting wall planes.
CORNER INTERSECTION INTERSECTION CORNER SINGLE MAT DOUBLE MAT (4) #5 VERT TYP UNO CORNER BAR MAY BE USED IN LIEU OF BEND 90° HOOK TYP (2) #5 VERT TYP UNO ALTERNATE BENDS TYP SPLICE HORIZ LAP SPLICE HORIZ LAP SPLICE HORIZ LAP SPLICE HORIZ LAP
