An elevator rail support constructed with an HSS6x4x3/8 member tied back using two three-quarter-inch diameter welded threaded rods at three inches on center on each side. An L4x4x3/16 angle is positioned on each side of the elevator rail support. A three-quarter-inch diameter all-thread with a nut and washer is installed in a sleeve.
L4X4X3/16 EA. SIDE OF ELEV. RAIL SUPPORT 3/4"Ø ALL-THREAD W/ NUT & WASHER IN LSLV HSS6x4x3/8 ELEV. RAIL SUPPORT (2) 3/4"Ø WELDED THRD. RODS @ 3" O.C., EA. SIDE HSS8x6
