Hollow structural section soffit framing ties into supporting steel beams, girts, and column grid lines A and B. The assembly utilizes L4x4x1/4 angles connected with 3/8-inch thick connection plates and two 3/4-inch diameter A325-SC-OVS bolts spaced at 3 inches on center. Fillet welds of 1/4-inch size and complete joint penetration welds with ultrasonic testing (CJP UT) secure the structural steel components. Architectural elements including wall panels, soffit panels, and a hangar door interface with the steel framing according to specified architectural drawings.
A B 2'-10" 1'-1 1/2" * 1'-10 1/2" * 13'-0" * GIRT PER EL TYP BOS EL 165'-2" PL3/8X3X0'-6 1/2" W/ (2) 3/4" DIA A325-SC-OVS BOLTS AT 3" OC L4X4 PER NOTE 8/S-160 S-160 1/4 1/4 1/4 3 NS&FS CJP UT HSS SOFFIT FRMG PER PLAN L4X4X1/4 L4X4X1/4 1/4 1/4 PL3/8X5 1/2X0'-6 1/2" W/ (2) 3/4" DIA A325-SC-OVS BOLTS AT 3" OC WALL PANEL PER ARCH DWG A-351 - A-353 HANGAR DOOR PER ARCH DWG A-422 TYP SOFFIT PANEL PER ARCH DWG A-351 - A-353 BM PER PLAN TYP L4X4X1/4
