An electrical control diagram outlines the wiring and indicator configuration for a supply fan designated SE020FP900 operating at 480V. The system is managed through a starter unit 70-FVNR-503-01 equipped with yellow indicator lights for ON and OFF states, along with an alarm indicator for failure status. A remote control station 70-FP-503-01 provides local-remote, start, stop, and reset pushbuttons connected via control lines.
HS 70-503-011 LR HS 70-503-012 ST HS 70-503-013 SP HS 70-503-014 RESET )915 480V )3 SF SUPPLY FAN SE020NSWPMCC03-1 SE020FP900 YL 70-503-012 OFF YA FAIL YL 70-503-011 ON
