A glulam column connects to a glulam beam supporting a cross-laminated timber floor plate, utilizing a sleeved pipe connection and four structural screws spaced per plan. The end of the beam aligns with the far side of the glulam column. Three-quarter by four-inch smooth steel dowels are positioned at the corners of the bearing plate. Additional steel plate assembly information is referenced on sheet S7.04.
A A SLEVED PIPE-PIPE CONN. REF. 1/S7.04 FOR BALANCE OF STEEL PLATE ASSEMBLY INFORMATION GL BEAM REF. PLAN (4) SDCP27912 SCREWS 2" 2" 3" GL COL. REF. PLAN TYP. CLT REF. PLAN ALIGN END OF BEAM w/ FAR SIDE OF COL. 3/4"x4" SMOOTH STEEL DOWELS AT CORNERS OF BEARING PL.
