This structural steel connection joins a hollow structural section member to a wide flange beam support. A three-eighths-inch cap plate is positioned on each side and extends a minimum of three-eighths of an inch past the edge of the hollow structural section slot. The hollow structural section is slotted at its centerline to fit top and bottom shear plates of thickness t. Erection bolts are provided as required, and five-sixteenth-inch welds secure the cap plate to the hollow structural section on each side. Weld sizes and plate thicknesses are detailed per the connected beam schedule, with a maximum two-inch offset dimension.
NOTES: 1. SIMILAR CONDITIONS APPLY FOR BEAMS ON BOTH SIDES OF MEMBER 'A'. 2. FOR WELD SIZE 'F', & PL THICKNESS 't' SEE BOLTED BEAM CONNECTION SCHEDULE 3/8" CAP PL EA SIDE, EXTEND 3/8" MIN PAST EDGE OF HSS SLOT CAP PL & HSS AT CENTERLINE OF HSS TO FIT SHEAR PL T & B MEMBER 'B' PL THICKNESS 't' MEMBER 'A' 2" MAX. 5/16 CAP PL. TO HSS EA. SIDE 'F' 'F' 'F' 3 'F' 3 T & B ERECTION BOLTS, AS REQ'D 'F' 'F' 2" 1"
