All slab reinforcement extends continuously through the joint. The joint depth is set with a keyway whose depth equals one-half of the slab thickness typically, or alternatively, the entire surface is intentionally roughened at the contractor's option. Edge spacing and maximum dimensions govern the placement of keys and reinforcement along the slab edge.
6" 30" MAX 6" 6" MIN EDGE OF SLAB ALL SLAB REINF SHALL EXTEND THRU JT DEPTH OF KEY SHALL BE 1/2 SLAB THICKNESS, TYP. OR, INTENTIONALLY ROUGHEN ENTIRE SURFACE AT CONTR OPT NOTES: PLAN 1 1/2" 30" MAX TOP BARS PER PLAN
