A steel guardrail post connects to a stair stringer using a one-quarter-inch-thick typical stiffener plate welded with a three-sixteenth-inch fillet weld. The stair fabricator provides a one-and-a-half-inch diameter steel pipe handrail atop the stringer in accordance with the California Building Code and architectural drawings.
GUARDRAIL POST TO STRINGER 7 NOTE: 1/4" THICK STIFF. PL. AT HANDRAIL POST, TYPICAL 3/16 TYP. STAIR FABRICATOR TO PROVIDE PIPE METAL RAIL ON TOP OF STRINGER IN ACCORDANCE WITH C.B.C. 1 1/2" DIA. ARCHT'L DRAWINGS (PROVIDE SHOP DRAWINGS) 3/16 STEEL PIPE HANDRAIL . FOR PROFILE SEE
