Metal deck support details at structural steel columns utilize L3x3x1/4 structural steel angles positioned at a maximum spacing of four inches. Alternate angle locations are provided with three-sixteenths inch fillet welds. Angles may be omitted where all vertical legs of the metal deck fall outside the unsupported region.
L3X3X1/4 TYP L3X3X1/4 ALTERNATE LOCATION L3X3X1/4 ALTERNATE LOCATION REGION UNSUPPORTED REGION UNSUPPORTED NOTE: WHERE ALL VERT LEGS OF DECK FALL OUTSIDE OF UNSUPPORTED REGION, ANGLES MAY BE OMITTED. DECK SPAN DIRECTION 3/16 3/16 3/16 3/16 4" MAX 4" MAX TYP 3 S-610
