An exterior steel stair features C12x20.7 structural steel channel stringers anchored to the building structure. The stringer connection utilizes a 3/8-inch by 12-inch by 1'-0" plate secured with four 3/4-inch diameter Hilti Kwik Bolt TZ expansion anchors. A secondary 1/4-inch by 4-inch by 0'-9" plate with three 5/8-inch diameter machine bolts fastens the stair assembly. A 1/4-inch fillet weld connects the steel channel elements per plan. Guardrails are coordinated per architectural drawings, and concrete panel reinforcement references detail 6 on sheet SD2.
1/4 PL 1/4x4"x0'-9" W/ (3) 5/8"Ø MB PL 3/8"x12"x1'-0" W/ (4) 3/4"Ø HILTI KWIK BOLT TZ (ESR-19917) 4" CHANNEL PER PLAN ENLARGED X-X 4 - TYP INTERIOR SEE ENLARGED DETAIL X-X GUARDRAIL SEE ARCH DWG C12x20.7 TYP SEE FOR PANEL REINF 6 SD2 2 - 3 -
