Reinforcing steel details for a concrete grade beam corner specify number six corner bars at the top and bottom with a one foot four inch lap splice length. The assembly maintains a typical three inch concrete clearance. Two number six bars run top and bottom along the member with a maximum grid spacing of six feet zero inches.
GRID MAX. 6' - 0" LAP SPLICE LAP SPLICE 1' - 4" 1' - 4" 1' - 4" NOTES: TYP. 3" CLR. (E) GRADE BEAM #6 CORNER BAR TOP AND BOTTOM, TYP. REF. SECTION VIEW FOR SIM ENFORCING (2) #6 T&B 11"
