Structural support for deck openings ranging from 24 to 60 inches in width. The perimeter of the opening is framed with L6x3x5/16 structural steel angles, unless otherwise noted on the plan. Steel deck flutes must be adjusted as required to ensure proper bearing on the supporting angles. All framing members are to be furnished and installed in accordance with structural steel specifications.
Text on the drawing
STEEL DECK WIDE FLANGE OR STEEL JOIST BEAM REF PLAN L6X3X5/16 UON ON PLAN, TYP NOTES: 1. FRAMING TO BE FURNISHED AND INSTALLED WITH STRUCTURAL STEEL. TYP C DECK OPENINGS >24" TO 60" 60" MAX 60" MAX A A ADJUST DECK FLUTES AS REQD TO ACHIEVE DECK BEARING ON ANGLES
