An anchor bolt is embedded into a concrete wall with specified minimum embedment depths varying by bolt size from half an inch to one inch. Minimum bolt spacing is twelve bolt diameters with a minimum edge distance of six diameters. A two-inch minimum embedment is required unless noted otherwise.
BOLT EMBEDMENT SCHEDULE 1/2" 3/4" 5/8" 7/8" BOLT SIZE 1" 7" 5" 6" 5" 5" EMBEDMENT FACE OF CONC NOTE: MINIMUM BOLT SPACING SHALL BE 12 BOLT DIAMETERS WITH A MINIMUM EDGE DISTANCE OF 6 DIAMETERS. SEE SCHEDULE MIN EMBEDMENT UNO 2" MIN
