Cold-formed steel wall framing is anchored to a concrete foundation with continuous 18-gauge track fastened by Hilti-XU shot pins at sixteen inches on center, positioned above exterior grade. Six-inch 18-gauge studs are spaced at sixteen inches on center with wall finishes per architectural specifications. At the intermediate junction, continuous 18-gauge track is secured with Hilti-XU shot pins at sixteen inches on center tying the upper and lower stud framing together.
EXTERIOR GRADE 1'-0" MIN 6" 1 1/2" TYP 18 GA. CONT TRACK W/ HILTI-XU SHOT PINS @ 16" OC B A 18 GA. CONT TRACK W/ HILTI-XU SHOT PINS @ 16" OC 6" x 18 GA. STUDS @ 16" OC WALL FINISH SEE ARCH'L
