A steel beam connects to a structural steel girder web using one-inch diameter A490X bolts sized per the non-moment connection schedule, with a centerline of bolts spaced three inches maximum and three inches typical. One-half-inch stiffener plates are welded to each side of the girder web with three-eighths-inch fillet welds on three sides typical. The stiffener plates match the beam width except for a four-and-one-half-inch minimum width at the shear plate. Plates are designed for A572 Grade 50 steel. This condition applies when dimension d1 is less than dimension d2 plus six inches.
NOTES: 1. PROVIDE WHEN SHOWN THUS ON PLAN: 2. SEE TYPICAL SHEAR PLATE DETAILS FOR INFO NOT NOTED. 3. PLATES DESIGNED FOR A572, GR 50 GIRDER PER PLAN BEAM PER PLAN C L BOLTS 1/2" MIN. 2" MIN. 2" MIN. 1/2" STIFF PL EACH SIDE. PL TO MATCH BEAM WIDTH EXCEPT 4 1/2" MIN. WIDTH AT SHEAR PL. 3/8 3/8 3 SIDES, TYP. 1" DIA A490X BOLTS. SEE NON-MOMENT CONNECTION SCHEDULE FOR NUMBER 3" MAX. 1 3/4" 3" 3" TYP. 1 3/4" MIN. d1 CONDITION A: d1 < d2 + 6" d2 BF
