An HSS screen frame connects at a building corner to a wide-flange column using an angle brace and bolted connections. The assembly features hollow structural sections framing the screen, supported by a diagonal angle brace referenced for connection details. Bolted connections secure the members together at the column flange and the frame intersection.
C 2 HSS SCREEN FRAME REF. PLAN REF. 8/S6.05 FOR CONNECTION OF HSS TO WF COLUMN REF. PLAN REF. 2/S6.05 FOR ANGLE BRACE HSS SCREEN FRAME REF. PLAN
